4729000550 Max. operating pressure:20.0 bar for daf,volvo benz ecas solenoid valve Custom

4729000550 Max. operating pressure:20.0 bar for daf,volvo benz ecas solenoid valve

Contact us

  • Details
  • Type of vehicle
  • Leave a message
  • 4729000550 Max. operating pressure:20.0 bar for daf,volvo benz ecas solenoid valve

    REF No.: BT4729000550

    APPLICATION: DAF IVECO
    Ports: 11,21,22,23,25=M22x1.5
    24V DC

    Application:

    Rear axle

    Electrical Connection:

    Bayonet (DIN)

    Max. operating pressure:

    20.0 bar

    Multi Nominal diameter (From Port 1 to x):

    9.8 / 7.0 / 0.6 mm

    Port thread 11:

    M22 x 1.5 JED - 388

    Port thread 21:

    M22 x 1.5 JED - 388

    Port thread 22:

    M22 x 1.5 JED - 388

    Port thread 23:

    M22 x 1.5 JED - 388

    Port thread 3:

    Silencer 432 407 0600

    Port threads:

    M22 x 1.5 Parker

    Protection Class:

    IP 6K6K

    Rated Current:

    320 mA

    Temperature range:

    -40°C to +80°C

    Voltage:

    24 V

    Calculated Volume (dm³):

    2.7547

    Size (mm x mm x mm):

    178 x 212 x 73

    Weight (kg):

    2.365

    Weight (lb):

    5.2139

    Application:

    ALEXANDER DENNIS,DAF,DOLL,FAYMONVILLE,FELDBINDER GOLDHOFER,ISUZU,KRONE,KÄSSBOHRER,KÖGEL,LANGENDORF,LEYLAND DAF MAN,Meiller,NEOPLAN,SCANIA,SCHMITZ CARGOBULL,SCHWARZMÜLLER,Tirsan,VDL,VOLVO

Zhuji Oubote Auto Parts Co., Ltd.

Zhuji Oubote Auto Parts Co., Ltd. as China Custom 4729000550 Max. operating pressure:20.0 bar for daf,volvo benz ecas solenoid valve Suppliers,Our factory specializes in manufacture of air brake parts for commercial vehicles, semi trailers and heavy vehicles. Its main products are: foot brake valve, unload valve, trailer valve, hand brake Valve,load sensing valve, leveling valve, relay valve, air dryer, clutch servo and so on. Some products are matched with large domestic automobile manufacturers and exported to Southeast Asia, America, the Middle East, Africa and other regions.
Q. Where are your goods mainly exported?
Our products are mainly exported to Egypt, Nigeria, the United States, Chile, Brazil, Argentina, Turkey, Iran, Iraq, Dubai, Russia, Auckland, Algeria and dozens of other countries and regions.
Q. How to deliver goods to customers?
According to Customers requirement. Any shipment is available from us.
