  • What is a protection valve?
    Application: Tractor protection valves are commonly mounted at the rear of the cab. The purpose of the Tractor Protection valve is to protect the tractor air brake system in the event of a trailer breakaway or severe air leak. They are also used to shut off air to the trailer before disconnecting the lines.

    Charging pressure:

    3.5 bar

    Closing pressure dynamic 21:

    6.4 bar

    Closing pressure dynamic 22:

    6.4 bar

    Closing pressure dynamic 23:

    6.4 bar

    Closing pressure dynamic 24:

    6.4 bar

    Max. operating pressure:

    13.0 bar

    Opening pressure 21:

    6.9 bar

    Opening pressure 22:

    6.9 bar

    Opening pressure 23:

    7 bar

    Opening pressure 24:

    6.9 bar

    Opening pressure circuit 1+2:

    7.0 + 6.9 bar

    Port thread 1:

    M22 x 1.5

    Port thread 21:

    M16 x 1.5

    Port thread 22:

    M16 x 1.5

    Port thread 23:

    M16 x 1.5

    Port thread 24:

    M16 x 1.5

    Port thread 4:

    M16 x 1.5

    Pressure sensor:

    No

    Temperature range:

    -40°C to +90°C

    Type:

    dynamic

    Calculated Volume (dm³):

    0.86328

    Size (mm x mm x mm):

    109 x 90 x 88

    Weight (kg):

    0.674

    Weight (lb):

    1.4859

    APPLICATION:

    FAW NEOPLAN,MAN
