4728800300 Max. operating pressure:20.0 bar ecas solenoid valve Wholesale

4728800300 Max. operating pressure:20.0 bar ecas solenoid valve

Contact us

  • Details
  • Type of vehicle
  • Leave a message
  • What is an ECAS valve?
    In an ECAS (Electronically Controlled Air Suspension) system, the ECU outputs signals to the Solenoid Valve, which in turn provides pneumatic actuation control of the air suspension bellows. FUSO (MITSUBISHI)

    Technical Specification:

    OE specification

    Electrical Connection

    Bayonet DIN 72585-A1-4.2-Sn/K2

    Max. operating pressure

    20.0 bar

    Mounting

    2 x Ø 9 mm

    Multi Nominal diameter (From Port 1 to x)

    9.8 / 7.0 / 0.6 mm

    Port thread 11

    M22 x 1.5 JED - 388

    Port thread 21

    M22 x 1.5 JED - 388

    Port thread 22

    M22 x 1.5 JED - 388

    Port thread 23

    M22 x 1.5 JED - 388

    Port thread 3

    Silencer 432 407 060 0

    Protection class

    IP 6K9K / IP 6K6K

    Push-rod thread

    M22 x 1.5

    Rated current

    320 mA

    Temperature range

    -40°C to +80°C

    Voltage

    24 V

    Calculated Volume (dm³)

    2.499

    Size (mm x mm x mm)

    167 x 205 x 73

    Weight (kg)

    2.203

    Weight (lb)

    4.857

    Application:

    Feldbinder, Iveco, Krone, Kenworth, King Long, Leyland Daf, Lohr,Man, Meritor, Meiller, Nooteboom, Ashok Leyland,Daf,Faw, Renault,Volvo, SchwarzmüLler

Zhuji Oubote Auto Parts Co., Ltd.

Zhuji Oubote Auto Parts Co., Ltd.

Zhuji Oubote Auto Parts Co., Ltd. as Wholesale 4728800300 Max. operating pressure:20.0 bar ecas solenoid valve Supplier and Custom 4728800300 Max. operating pressure:20.0 bar ecas solenoid valve Company, Our factory specializes in manufacture of air brake parts for commercial vehicles, semi trailers and heavy vehicles. Its main products are: foot brake valve, unload valve, trailer valve, hand brake Valve,load sensing valve, leveling valve, relay valve, air dryer, clutch servo and so on. Some products are matched with large domestic automobile manufacturers and exported to Southeast Asia, America, the Middle East, Africa and other regions.
Q. Where are your goods mainly exported?
Our products are mainly exported to Egypt, Nigeria, the United States, Chile, Brazil, Argentina, Turkey, Iran, Iraq, Dubai, Russia, Auckland, Algeria and dozens of other countries and regions.
Q. How to deliver goods to customers?
According to Customers requirement. Any shipment is available from us.
